| MODEL No. | DFACM-1000 |
| SPACE REQUIRED | *STANDARD WORKING AREA (15 FT. x 5.5FT. APP. ) |
| CAPACITY | ACCOUNTABLE 900-1060 CHAPATIES / HR( UP TO 6 Kgs Dough) |
| BODY | STAINLESS STEEL ( FOOD GRADE SS 304 )FOR IN TOUCH WITH CHAPATI & DOUGH SECTION |
| TYPE OF MACHINE | PEDA TYPE ROLLER MODEL / ROTARY BAKING OVEN |
| GEAR BOX | Heavy Duty |
| EFFECTIVE ROLLERS | AUTOMATION WITH TWO NUMBER FOR PRESSING WITH STANDARD GEAR BOX |
| CHAPATI DIAMETER | 4″ TO 7’’ APPROX. (MAX.) |
| LOCKING FACILITY | YES / OPTIONAL |
| THICKNESS OF CHAPATI | ADJUSTABLE FROM 1 to 3 MM APPROX. |
| STRUCTURE | ALL METAL |
| APPEARANCE | SOFT WITH PUFFED LAYER |
| WEIGHT OF CHAPATI | 20 TO 55 GM |
| BAKING SYSTEM | TOP & BOTTOM, DOUBLE STAGE (BOTH SIDE ) CONCENTRATED BAKING WITH 3 TIER CONVEYOR AUTOMATION SYSTEM FOR PERFECT COOKING |
| SAFETY FEATURES | CONTROL PANNEL WITH MAIN WARNING LAMP, PUSH BUTTON PROVIDED / OPTIONAL |
| TEMPERATURE DISPLAY | ELECTRONICAL DEGITAL TEMPERATURE DISPLAY /OPTIONAL |
| CONSUMPTION OF GAS | 0.60 TO 1.25 KG/HR. (1700 GR TO 1800 GR) |
| REQUIRED GAS PRESSURE | 5 PSI TO 7 PSI |
| BURNERS | 2 TOP + 2 BASE = 4 BURNERS |
| EGNITION | THROUGH PILOT BURNER |
| FUEL | ELECTRIC / LPG OR PNG OPTIONAL |
| ELECTRONIC POWER | 440 V 50HZ ( MOTOR + HEATER 1.2 KW) |
| MOTOR | 1 NO. |
| CHAPATI COLOUR | LIGHT BROWN |
| SIZE | 1800 (L)X 1200 (W)X 1800 (H) APPROX. (Available 6.0 Ft to 15 FT. x 5.5 FT. APP. ) |
| WEIGHT | 1500- 400 Kgs (Appr.) Optional |
| MOBILE | OPTION / STATIONED OR WITH HEAVEY DUTY PU WHEELS WITH BRAKE PROVIDED |
| LUBRICATION REQUIRED | YES GREASE AND OIL CONSUMPTION DEPAND ON USES |
| MAN POWER | SINGLE |
| Country of Origin | Made in India |
| | |
| *Subject to Model | |
| Specification, Space veries from model to model |
| Can be customised as per the client requirement |
